10 MPa single acting uniform speed rod action 2-stage telescopic cylinders
- Single acting uniform speed telescopic cylinders
- 2-stage stroke cylinders require smaller installation space in the axial direction.
- Since the stages operate simultaneously, the rod end speed is uniform.
- Both stroke ends are provided with fixed cushions.
- The structure with high rigidity is suitable for lifting long articles.
