Tube flange type heavy-duty hydraulic cylinders for 14 MPa
- 14 MPa tube flange type double acting hydraulic cylinders with bores size from 63 to 160 mm applicable to strokes length from 200 to 3000 mm.
- High-performance cushion reduces a shock at stroke-end.
- Newly designed cushion valve allows easy cushion adjustment.
- The drop prevention mechanism and looseness preventive lock nut have been adopted as safety measures for the cushion valve.
- The adaption of O-ring seal for cover and screwed tube flange.
- The use of more durable mounting accessories than those of 140H-8
