21 MPa compact design hydraulic cylinders with magnetic proximity sensors developed first in the industry
- 21 MPa compact design hydraulic cylinders. Sufficient strength verified by fatigue test and pressure test.
- The adoption of AX/AZ type sensors with high maintainability as standard.
- Switch Set cylinders can be used at up to 100℃ depending on the selection of sensors.
- The mounting hole pitch is completely compatible to 100S-1 Series and 160S-1 Series. (The length in the stroke direction is different.)
