21 MPa position sensing cylinders using absolute method
- Now even more compact. (compared to the PTT-1B) Total cylinder length: Shortened by up to 43mm
- The position sensor applying a magnetostriction phenomenon enables high-accuracy absolute position detection.
- There is no need for a switch for the original position settings.
- Compact design.
- Cushions available at either end.
